>>  flexible and clean

       This machine was developed for operating with
       combined waste such as that generated by
       restaurants, hotels, ski lodges and large catering
       facilities, etc.  Thanks to a special press system,
       the residual waste is compacted in a steel cylinder
       and then forced into the fitted refuse bag.  This
       system prevents the refuse bags from being
       damaged.






                                                  technical data

                                               Maxi

            compression force    kN             30

                 motor 400v *  kW               1.5

              comp. time incl.
                 return stroke   sec            30
                press cylinder  ø x h        550x750


             loading aperture.  mm             550                                                              h1
                                                                                                 h
               Loading height  mm              900


                   bag weight    kg            ~ 30
            overall dimensions   mm      700x1260x1950
                        wxdxh                                            t               b
     conformity  changing bag  mm              2550


                                               1050
                   total weight  350
                                          technical data subject to change
                                                  product range











                                       We can supply:

                                       vertical & horizontal baling presses;
                                       semi & fully automatic channel baling presses;
                                       can and barrel presses;
                                       fully automatic can crushers;
                                       waste compactors;
                                       stationary presses;
                                       tipping devices;
                                       chain belt conveyors;
                                       reel splitting machines
